Technical Specifications
| SPECIFICATION | IB-DPBA-36-12 | IB-DPBA-36-24 | |
|---|---|---|---|
| OUTPUT | Rated DC voltage | 12V±0.5V | 24V±0.5V |
| INPUT | Voltage range | AC100-250V (AC110V maximum load does not exceed 60%) |
Technical Specifications
| PROTECTION | Over Current | 105%-130% |
|---|---|---|
| ENVIRONMENT | Working TEMP. | -20℃-45℃ |
| SAFETY&EMC | Safety Standards | Design refer to LVD EN61347-2-13:2006, EN61347-1:2008 |
| OTHERS | MTBF | 50,000 Hours (25℃) |
Technical Specifications
| Release Date | Issuance of Category |
|---|---|
| 2025.09.01 The 1st. Version |
