Technical Specifications
| Code | IB-NS-UL-SB24xxx-4.8W-1220-y (xxx: 2700K: 927, 3000K: 930, 4000K: 940, 6000K: 960; y: IP67: A, IP68: B) |
|---|---|
| Electronic data | |
| Input voltage | 24VDC |
| Rated Power | 4.8W/m |
| Optical / Photometric | |
| LED type | SMD 2835 |
| LED Qty/m | 120 LEDs/m |
| Lumen / meter @ 2700K | 149 lm |
| Lumen / meter @ 3000K | 158 lm |
| Lumen / meter @ 4000K | 165 lm |
| Lumen / meter @ 6000K | 165 lm |
| CCT | 2700K / 3000K / 4000K / 6000K |
| CRI | ≥ 90 |
| SDCM | < 3 |
| Beam angle | 120° |
| Mechanical | |
| Dimension / reel (L*W*H) | 50000*11.5*20mm |
| Housing material | Silicone |
| Ingress protection | IP67 / IP68 (optional) |
| Cutting length | 50mm |
| Others | |
| Rated lifetime | 50,000 hrs |
| Operating Ambient | 20~45°C |
| Certification | RoHS, CE, UL |
Technical Specifications
| Code | IB-NS-UL-SB24xxx-9.6W-1220-y (xxx: 2700K: 927, 3000K: 930, 4000K: 940, 6000K: 960; y: IP67: A, IP68: B) |
|---|---|
| Electronic data | |
| Input voltage | 24VDC |
| Rated Power | 9.6W/m |
| Optical / Photometric | |
| LED type | SMD 2835 |
| LED Qty/m | 120 LEDs/m |
| Lumen / meter @ 2700K | 296 lm |
| Lumen / meter @ 3000K | 313 lm |
| Lumen / meter @ 4000K | 329 lm |
| Lumen / meter @ 6000K | 329 lm |
| CCT | 2700K / 3000K / 4000K / 6000K |
| CRI | ≥ 90 |
| SDCM | < 3 |
| Beam angle | 120° |
| Mechanical | |
| Dimension / reel (L*W*H) | 30000*11.5*20mm |
| Housing material | Silicone |
| Ingress protection | IP67 / IP68 (optional) |
| Cutting length | 50mm |
| Others | |
| Rated lifetime | 50,000 hrs |
| Operating Ambient | 20~45°C |
| Certification | RoHS, CE, UL |
Technical Specifications
| Code | IB-NS-UL-TB24xxx-14W-1220-y (xxx: 2700K: 927, 3000K: 930, 4000K: 940, 6000K: 960; y: IP67: A, IP68: B) |
|---|---|
| Electronic data | |
| Input voltage | 24VDC |
| Rated Power | 14W/m |
| Optical / Photometric | |
| LED type | SMD 2835 |
| LED Qty/m | 120 LEDs/m |
| Lumen / meter @ 2700K | 432 lm |
| Lumen / meter @ 3000K | 456 lm |
| Lumen / meter @ 4000K | 480 lm |
| Lumen / meter @ 6000K | 480 lm |
| CCT | 2700K / 3000K / 4000K / 6000K |
| CRI | ≥ 90 |
| SDCM | < 3 |
| Beam angle | 120° |
| Mechanical | |
| Dimension / reel (L*W*H) | 20000*11.5*20mm |
| Housing material | Silicone |
| Ingress protection | IP67 / IP68 (optional) |
| Cutting length | 50mm |
| Others | |
| Rated lifetime | 50,000 hrs |
| Operating Ambient | 20~45°C |
| Certification | RoHS, CE, UL |
Technical Specifications
| Release Date | Issuance of Category |
|---|---|
| 2025.07.21 The 1st. Version |
